The Fostex NX-6A Nearfield active monitors. Powered Nearfield Studio Monitor designed to provide studios and DAW users with simply the best nearfield reference monitoring available.



The Fostex NX-6A monitor features many of the smart technologies which have made the Fostex NF Series so successful including HP sound reflectors to prevent unwanted standing waves and introducing new features such as a HR (Hyper Radial) diaphragm which utilises the latest diaphragm Radial Papermaking Technology for natural and smooth sound reproduction, and the UDR (Up/Down Roll) Tangential edge to the LF unit which negates unwanted resonance and virtually eliminates hearing fatigue, the NX-6A can only build on the NF Series' reputation.



The Fostex NX6A offers amazing clarity and transparency of sound plus virtually distortion-free operation even at the highest sound pressure levels while offering full-frequency performance from 55 Hz to 38 kHz.



The main features of the Fostex NX-6A include:



Powered Nearfield Studio Monitor designed to provide studios and DAW users with simply the best nearfield reference monitoring available

Tight and detailed sound

Good stereo imaging

Low Frequency Unit: 6.5 inch (160mm) with HR (Hyper Radial) diaphragm which utilises the latest diaphragm Radial Papermaking Technology for natural and smooth sound reproduction

UDR (Up/Down Roll) Tangential driver edge eliminates the unwanted resonance

Wide-range 20mm hard dome tweeter, employs magnesium diaphragm which eliminates metallic characteristics and features ultra-fast high frequency response

LF and HF units feature highly rigid cast aluminum frames minimizing unnecessary vibrations and resonances

Magnetically shielded drivers allow for safe placement close to a video monitor

Time-aligned front baffle enclosure design with the recessed HF driver for a sharply focused sound image

Unique HP sound reflectors prevents the generation of standing waves in the enclosure

Bi-amplifier: Dedicated 60W (LF) + 40W (HF) bi-amplifier eliminates electric interference between the drivers

Overall output level control

Dedicated tweeter level control (3dB) cut/boost

LO EQ control : 3d cut/boost around 55Hz for optimum performance in varying environments

Input - Balanced Connector XLR-3-31 type (Pin 2:HOT) x 1, Impedance > 10k ohm, Level +4dBu

Input - Unbalanced Connector 6mm phone (1/4 inch) jack x 1, Impedance > 10k ohm, Level -10dBV

Dimensions 230(W) x 350(H) x 334(D)mm

Weight Approx. 13kg
